Product Code: SPDFI115CT
Availability: Next Day Special Order
The EM115 is a compact CT operated meter designed for use on single phase supplies. It’s MID approved, making it suitable for billing applications and has Class B accuracy, (equivalent to Class 1).
It’s easy read back lit LCD screen displays Active Energy (kWh), Active Power, (W), Voltage (V), Current (I), Power Factor and Frequency. It measures both imported & exported energy and comes with Modbus & Pulse outputs, ideal for integration into a BMS system or metering gateway.
N.B. This meter can be supplied pre-wired into a suitable DIN rail enclosure for easier installation on site. Please use the link below for more information:
https://www.spwales.com/metering-kits/single-phase-metering-kit
| Meter Type | Single Phase |
| Fitting Type | DIN Rail |
| Max Current (amps) | 5 |
| MID Approved | Yes |
| Input Type | Current Transformer |
| Output Type | Modbus Pulse |
| Smart | No |
| Tariffs | Single |
| Import / Export | Import & Export |
| Accuracy Class | B (Cl. 1) |
| Fuse Type (Auxiliary) | n/a |
| Fuse Type (Voltage Ref.) | 1A |
| Module Width | 1 |
| Availability | Next Day |
| Brand | Fineco |
| Country of Manufacture | China |
| Meter Type | Single Phase |
| Fitting Type | DIN Rail |
| Max Current (amps) | 5 |
| MID Approved | Yes |
| Input Type | Current Transformer |
| Output Type | Modbus Pulse |
| Smart | No |
| Tariffs | Single |
| Import / Export | Import & Export |
| Accuracy Class | B (Cl. 1) |
| Fuse Type (Auxiliary) | n/a |
| Fuse Type (Voltage Ref.) | 1A |
| Module Width | 1 |
| Availability | Next Day |
| Brand | Fineco |
| Country of Manufacture | China |
