• Acrel - ADL400D

Acrel - ADL400D

by: Acrel

Product Code: TPDAC400D

Availability: Next Day Special Order

Download Summary Sheet

Quick overview

This direct connect DIN Rail meter is for use with three phase supplies and measures electrical parameters including Current (I), Voltage (V), Power (kW/KVA/KVAr), Power Factor (PF), Frequency (Hz), Imported, Exported and Total Energy (kWh/kVArh).

It’s MID approved, allowing it to be used for billing applications and is highly accurate, (Class B, ±1%). With both a Pulse Output and RS485 Modbus RTU it can be integrated with BMS or remote monitoring systems.

Optional Extras

Meter TypeThree Phase
Fitting TypeDIN Rail
Max Current (amps)100
MID ApprovedYes
Input TypeDirect Connect
Output TypeModbus & Pulse
SmartNo
TariffsSingle
Import / ExportImport & Export
Accuracy ClassB (Cl. 1)
Max. Cable Size35mm²
Module Width4
AvailabilityNext Day
BrandAcrel
Country of ManufactureChina
MEASURED PARAMETERS
Active Energy (kWh)Line Power Factor (PF)
Active Power (W)Line Reactive Power (kVAr)
Apparent Energy (kVAh)Line to Line Voltage (V)
Apparent Power (VA)Line to Neutral Voltage (V)
Average Current (I)Maximum Current (I)
Average Power Demands (W)Maximum Power Demands (W)
Average Voltage (V)Maximum Voltage (V)
Current (I)Power Factor (PF)
Current in Neutral (I)Reactive Energy (kVArh)
Frequency (Hz)Reactive Power (VAr)
Hours Run (hr)Total Harmonic Distortion (Amps)
Line Active Power (W)Total Harmonic Distortion (Volts)
Line Apparent Power (kVA)Voltage (V)
Line Current (I)
