by: Eastron
Product Code: TPDEA72D
Availability: Next Day Special Order
The SDM72D is a great value 100 Amp, 3 phase, DIN rail meter. Measuring just 4 modules wide, this meter is MID approved, making it suitable for billing applications and has Class B accuracy, (equivalent to Class 1).
It displays Energy (kWh) on its easy to read back-lit 6 + 1 LCD screen making it ideal for customers who require a very simple metering solution. It also features a pulse output set at 1000imp/kWh.
The Modbus variant will output the RS485 communication protocol make it ideal for connecting to a building management system.
The SDM72D is a great value 100 Amp, 3 phase, DIN rail meter. Measuring just 4 modules wide, this meter is MID approved, making it suitable for billing applications and has Class B accuracy, (equivalent to Class 1).
It displays Energy (kWh) on its easy to read back-lit 6 + 1 LCD screen making it ideal for customers who require a very simple metering solution. It also features a pulse output set at 1000imp/kWh.
N.B. This meter can be fitted into a DIN Rail enclosure. Click here to see our full range of Enclosures.
| Meter Type | Three Phase |
| Fitting Type | DIN Rail |
| Max Current (amps) | 100 |
| MID Approved | Yes |
| Input Type | Direct Connect |
| Output Type | Pulse or Modbus* |
| Smart | No |
| Tariffs | Single |
| Import / Export | Import & Export* |
| Accuracy class | B (Cl. 1) |
| Max. Cable Size | 25mm |
| Module Width | 4 |
| Availability | Next Day |
| Brand | Eastron |
| Country of Manufacture | China |
* Dependant on model selected
The SDM72D is a great value 100 Amp, 3 phase, DIN rail meter. Measuring just 4 modules wide, this meter is MID approved, making it suitable for billing applications and has Class B accuracy, (equivalent to Class 1).
It displays Energy (kWh) on its easy to read back-lit 6 + 1 LCD screen making it ideal for customers who require a very simple metering solution. It also features a pulse output set at 1000imp/kWh.
N.B. This meter can be fitted into a DIN Rail enclosure. Click here to see our full range of Enclosures.
| Meter Type | Three Phase |
| Fitting Type | DIN Rail |
| Max Current (amps) | 100 |
| MID Approved | Yes |
| Input Type | Direct Connect |
| Output Type | Pulse or Modbus* |
| Smart | No |
| Tariffs | Single |
| Import / Export | Import & Export* |
| Accuracy class | B (Cl. 1) |
| Max. Cable Size | 25mm |
| Module Width | 4 |
| Availability | Next Day |
| Brand | Eastron |
| Country of Manufacture | China |
* Dependant on model selected
